Clip-On Rail Fire Extinguisher 8-15s for Electrical Cabinets

Walax clip-on aerosol fire extinguisher for electrical cabinets, discharging in 8–15 seconds on thermal activation. Tool-free clip-on installation makes retrofit into existing enclosures quick and simple.

Tool-Free Clip-On

Snap-fits into cabinets without screws or drilling, enabling fast retrofits.

8–15s Discharge

Rapid aerosol release floods the enclosure before fire can develop.

Retrofit Ready

Designed to add fire protection to existing electrical cabinets with minimal effort.

Specifications

Technical Specifications

Standard ratings listed below – custom configurations available on request. Contact our engineers to confirm parameters for your market.

Certification	CE · ROHS
Extinguishing agent	Potassium-based aerosol compound
Discharge time	8 – 15 s
Activation	Thermal (heat-activated)
Activation temperature	≈ 170°C
Fire class	A / B / C (enclosed)
Mounting	Clip-on (no tools required)
Power supply	None required
Shelf life	10 years (maintenance-free)

Applications

Where These Units Install

Existing electrical cabinets, control panels and equipment enclosures where adding suppression after installation is required. The clip-on design avoids the need to modify the enclosure.
