AC SPD 2P 40kA 385V Type 2 Surge Protector
Walax 2-pole 40kA Type 2 AC surge protector rated 385V. Industrial-grade lightning arrester for single-phase distribution and control panels requiring robust surge diversion.
- Factory-direct pricing · OEM/ODM branding · IEC/CE compliance
- Wholesale & project supply to Africa, SE Asia & the Middle East
2P Configuration
Line-to-line and line-to-neutral protection for single-phase distribution.
40kA Imax
Industrial-grade surge capacity for demanding environments.
385V AC Rated
Suits both 230V single-phase and 400V phase-to-phase circuits.
Technical Specifications
Standard ratings listed below – custom configurations available on request. Contact our engineers to confirm parameters for your market.
| Standard | IEC 61643-11 · CE |
| Max continuous voltage (Uc) | 385V AC |
| Max discharge current (Imax) | 40kA |
| Nominal discharge current (In) | 20kA |
| Voltage protection level (Up) | ≤ 1.8kV |
| Type | Type 2 |
| Poles | 2P |
| Mounting | 35mm DIN rail |
| Ambient temperature | -40°C to +80°C |
Where These Devices Install
Single-phase industrial distribution, control panels and equipment feeds on 385V AC supplies where 2-pole surge protection is required.
Frequently Asked Questions
Send Us an Inquiry
Need AC SPD 2P 40kA 385V Type 2 Surge Protector Pricing?
Send your quantities and target delivery port – our export desk replies with a wholesale quotation within 4 business hours.
